Technical Information
CAPACITY INFORMATION
Hopper gross volume
5 m³
Fuel tank
100 lt
Payload capacity
5.450 kg
Water tank
540 lt
Hydraulic tank
100 lt
ENGINE INFORMATION
Brand - Model
4.500 cc 4 Cylinder Water Cooled FPT N45 ENT Diesel Engine
Power
141 hp / 104 kW @ 2.200 RPM
Torque
608 Nm @ 2.000 rpm
Emission
EPA Tier 3 and EU Stage 3A
Working speed
1.800 rpm
SWEEPING EQUIPMENTS
Front brush
Ø 500 mm (0 - 150 rpm Hydraulic Engine Driven)
Suction hose diameter
Ø 250 mm
Suction nozzle width
650 x 230 mm
Sweeping width
2.000mm - 2.300mm (With third brush 3.000mm)
Sweeping capacity
35.000 m²
Variable and adjustable brush speed
GENERAL INFORMATION
Tire size
215 / 75R 17.5
Wheelbase - Gross Vehicle Weight
1.805 mm / 11.500 kg
Dump height and angle
850 mm ve 50º ± 5º
Vacuum filter mesh area
1.8 m²
Hydraulic filtration
100 micron suction / 20 micron return
Irrigation pump information
11 lt. / 4 bar 24V
Climbing ability
25%
Garbage hopper structure
Stainless steel (AISI304)
Sweeping and cruising speed
0 - 15 km/h ve 40 km/h
Brake
Hydraulic type front and rear dynamic brake system
Suspension system
Front Hydropneumatic rear independent rubber suspension
Vehicle curb weight
6.060 kg
Wheel turning diameter
6.600 mm ±100
FAN
Type
Heavy duty, dynamically balanced impeller with multivane corrosion resistance blades
Operation speed
3000 - 4000 rpm
Fan air flow capacity
13.000 m³/ h
Construction material
Stainless steel (AISI304)
CABIN - CONTROL PANEL
Adjustable and telescopic hydraulic steering wheel
Suspension driver seat
Air conditioner
Radio-Usb-Aux
Engine RPM display
Engine operating hours
Water tank level indicator
Fuel level indicator
Camera system with in cabin 7" screen, rear view and suction nozzle cameras
Front display panel
Camera control system
Garbage hopper lift audible warning
OPTIONS
Camera control system
Front wheel maneuverability
Snow sweeping brush
Snow blade
Rear suction hose 5mt.
Front third brush
15lt / 150 bar high pressure pump with 10mt hose and washing gun
Magnet
