Technical Information
CAPACITY INFORMATION
Hopper volume
240 lt.
Battery
4 x 6V 240Ah Battery
Traction speed
6 km/h
Total weight
310 kg.
Charging and duration of operation
8-10 Hr. Charging Goes Up To 6-8 Hr Operation Time
Filter mesh area
18 m²
Impeller engine
Italian DC Engine
Traction engine
Italian DC Engine
Noise level
55 dBA
CONTROL PANEL
Emergency stop button
Steeples, forward and reverse handle
Optional
Horn and reverse audible warning
Trouble indication
LED headlight on/off button
GENERAL INFORMATION
Wheel diameter
Ø 400 mm
Loaded weight
485 kg.
Irrigation system
Bin Irrigation System
Chassis material
ST - 37
Body material type
Fiber Glass
Suction hose
Ø 125 mm. / 2.700 mm.
Suction pipe material
Lightweight Fiber Glass Suction Pipe
Wheelbase
1.213 mm
Machine width
842 mm
Machine height
2.128 mm
Grade abilty
25%
Steering rotating angle
150° ± 5°
Operation handle side
Right or Left Side
Air filter
Removable and Washable
Towing trailer
Optional
Warranty
1 year
*The machine can be safely run freewheeling in case on flat battery
