TECHNICAL INFORMATION
Maximum trunk diameter
30 cm
Maximum root ball diameter
230 cm
Root ball depth
155 cm
Maximum working pressure
230 bar
Hydraulic flow rate
84 lpm
Vehicle width
255 cm
Vehicle height
412 cm
Weight of transplanter
8.800 kg.
Water tank capacity
1.500 lt.
Hydraulic oil tank
200 lt.
Tree Size (cm)
KDM - 50
6
KDM - 65
8
KDM - 85
10
KDM - 100
13
KDM - 125
16
KDM - 150
18
KDM - 175
22
KDM - 200
26
KDM - 230
30
Ball Diameter (cm)
KDM - 50
50
KDM - 65
65
KDM - 85
85
KDM - 100
100
KDM - 125
125
KDM - 150
150
KDM - 175
175
KDM - 200
200
KDM - 230
230
Digging Depth (cm)
KDM - 50
45
KDM - 65
55
KDM - 85
65
KDM - 100
80
KDM - 125
100
KDM - 150
115
KDM - 175
133
KDM - 200
150
KDM - 230
175
Water Pressure (bar)
KDM - 50
180
KDM - 65
180
KDM - 85
200
KDM - 100
200
KDM - 125
200
KDM - 150
220
KDM - 175
220
KDM - 200
220
KDM - 230
220
Water Tank (lt)
KDM - 50
***
KDM - 65
***
KDM - 85
***
KDM - 100
***
KDM - 125
***
KDM - 150
750
KDM - 175
1000
KDM - 200
1250
KDM - 230
1500
