Data
Technical Information
General information
Tire size
205/70 R15 C
Wheelbase
1,740 mm
Dump height
1,400 mm / 1,650 mm (from rotation center)
Climbing ability
27%
Hopper structure
Aluminum (ALMG3)
Sweeping and cruising speed
0 to 15 km/h sweeping, 30 km/h cruising
Traction motor power
Nominal 15 kW, peak 30 kW
Brake
Front drum, rear electrically regenerative disc
Suspension
Front hydropneumatic, rear independent shock absorber spring
Vehicle curb weight
2,900 kg
Tilting angle
90° ± 3°
Vacuum filter mesh area
0.35 m²
Hydraulic filtration
100 micron suction, 20 micron return
Irrigation pump
11 L/min, 3 bar, 12 V
Battery
Type
Lithium Iron Phosphate (LiFePO4)
Capacity
96 V 640 Ah
Charger
10 kW AC internal (included)
Sweeping equipment
Front brush
Ø 480 mm (0 to 100 rpm)
Suction hose diameter
Ø 200 mm
Suction nozzle
800 x 400 mm
Sweeping width
1,900 mm ± 50 mm
Sweeping capacity
28,500 m²/h
Brush speed
Variable from cabin
Capacity
Hopper gross volume
2 m³
Payload
1,700 kg
Water tank
400 L
Hydraulic tank
30 L
Cabin equipment
Adjustable telescopic hydraulic steering wheel
Ergonomic two-seat cabin (1 operator, 1 assistant)
Air conditioning and ventilation
Tiltable cabin for easy service access
Radio with USB and AUX
10-inch HMI screen with CANBUS control system
CAN joystick keypad for ergonomic control
Camera control system
High pressure washing system (15 L, 150 bar)
Hopper lift audible warning
Battery, water, motor rpm, and operating hour indicators
